Carpigiani UF
High-capacity twin-twist floor-standing machines for express gelato and soft serve, producing up to 1000 servings an hour.
Carpigiani UF models
Every model has its own page with full features, specifications and photos. Select a model to see it in detail.
Each UF model
UF 720 SP
Twin-twist floor-standing express gelato and soft serve machine with high production capacity. It produces up to 1000 servings in one hour.
Power Supply: 400v / 50hz / 3Ph
Cooling System: Air Cooling, Water Cooling
No of Flavours: 2 Flavours +
Flavours: 2+1
Tank Capacity: 11+11 for pump model; 17+17 for gravity model
UF 920 SP
Twin-twist floor-standing express gelato and soft serve machine with high production capacity. It produces up to 1000 servings in one hour.
Power Supply: 400v / 50hz / 3Ph
Cooling System: Air Cooling, Water Cooling
Feeding System: Gravity Feed, Pump Feed
No of Flavours: 2 Flavours +
Flavours: 2+1
UF specifications
| Specification | UF 720 SP | UF 920 SP |
|---|---|---|
| Power Supply | 400v / 50hz / 3Ph | 400v / 50hz / 3Ph |
| Cooling System | Air Cooling, Water Cooling | Air Cooling, Water Cooling |
| No of Flavours | 2 Flavours + | 2 Flavours + |
| Flavours | 2+1 | 2+1 |
| Tank Capacity | 11+11 for pump model; 17+17 for gravity model | 20+20 L; Gravity-fed version: Individual hopper capacity: 19 quarts (18 L); Total hopper capacity: 38 quarts (36 L). Pump-fed version: Individual hopper capacity: 13 quarts (12 L); Total hopper capacity: 26 quarts (24 L) |
| Cylinder Capacity | 2.5 L | 3.8 L |
| Rated Power Input | 4.8 kW | 8.7 kW (pump version); 8.5 kW (gravity version) |
| Fuse Size | 12 A | 20 A |
| Feeding System | – | Gravity Feed, Pump Feed |
| Hourly Production | – | 533+533 (pump version); 466+466 (gravity version) (75 g servings) |
| Net Weight | – | 486 kg (pump version); 456 (gravity version) |
Specifications are listed on each model’s page. Ask our team to confirm the right model for your site.
